30 GPM General Fluid Transfer Close Coupled Pump – Tri-Rotor Model 20CP
Click image to enlarge
Tri-Rotor Pump model 20CP, along with model 20D, is the smallest in the family of Tri-Rotor solid head pumps that provide constant flow rates. This low-cost pump is perfect for simple fluid transfer such as loading and unloading drums, totes, tanks, and trailers. The pump serves a wide range of industrial markets and applications including oil, diesel fuel, and chemical transfer.
This close-coupled double “C-flanged” mounted pump will provide years of trouble-free operation. By properly bolting the motor feet, this unit requires no base plate and is self-aligning.
The pump is designed with side suction and top discharge threaded ports and is available in both clockwise (CW) and counterclockwise (CCW) rotations for pump installation flexibility. Materials of construction for the 20CP model include Iron Fitted, All Iron, Bronze Fitted, or All Bronze configurations.
This close-coupled double “C-flanged” mounted pump will provide years of trouble-free operation. By properly bolting the motor feet, this unit requires no base plate and is self-aligning.
The pump is designed with side suction and top discharge threaded ports and is available in both clockwise (CW) and counterclockwise (CCW) rotations for pump installation flexibility. Materials of construction for the 20CP model include Iron Fitted, All Iron, Bronze Fitted, or All Bronze configurations.
Specifications of the Tri-Rotor Solid Head Pump Model 20CP:
- Flow rate: 4 to 30 GPM
- Viscosity range: 4 to 21,625 cPs (40 to 100,000 SSU)
- Inlet and Discharge Port size: 1-½” NPT Ports (std.) or 1-¼” NPT Ports
- Operating temperature range: -40 °F to 650 °F
- Maximum operating pressure: 125 PSI
- Pump displacement per revolution: 0.0176 gal/rev
- Pump speed range: 240 to 1800 RPM
- Solids passage available: 0.023 in.
Configure Your 20CP Solid Head Pump
Part Number:
20CP
Quantity:
Technical Information
Accessories
Please add a quantity to the following accessories before clicking the "Add to Quote Cart" button above to add items to your quote.
Tri-Rotor offers an interesting option for its’ 20CP solid head design: a Reduced Stroke Pump Head. With this option, the pump can be designed to target a specific flow rate at a percentage of full flow.
Other Options for the Solid Head Pump Model 20CP:
- Other Materials of Construction options:
- Shaft: Steel (std.), Stainless Steel, or Hardened Stainless Steel
- Piston: Iron (std.), Bronze, or Steel
- Body Gasket options:
- Standard {to 250 °F (121 °C)}
- Heat Resistant {to 650 °F (345 °C)}
- Shaft length: “CFM” (3-15/16”)
- Shaft seal: Type 68 Mechanical Seal – Viton {-40 °F to 300 °F (-40 °C to 150 °C)}
- Shuttle design: Formed Shuttle only
- Relieved Rotor Group (for higher viscosities: >10,000 SSU/2,150 cPs)
- Sanitary Preparation of pump internal components for food applications
- Lubrication: None required (lubricated for life)
- Exterior Protection: Orange Paint (std.), Black Paint, White Lacquer, or 316SS Epoxy Coating
The bare weight of the pump is approximately 16 lbs. The estimated shipping weight is 21 lbs.
Besides offering just a bare pump only for the Model 20CP, Tri-Rotor offers a complete mounted pump system, including motor drive assembly and mounting. Replacement parts for all Series 20CP pumps can be found here.
Besides offering just a bare pump only for the Model 20CP, Tri-Rotor offers a complete mounted pump system, including motor drive assembly and mounting. Replacement parts for all Series 20CP pumps can be found here.
